Display |
LCD Display |
Monochrome Graphical |
LCD Size |
132 × 64 pixel 2.3 inch Graphical LCD
160 × 384 pixel 5 inch Graphical LCD |
LCD Contrast |
6 levels |
LCD Backlight |
On/Auto/Off |
Install Options |
Desk Mount Tilt |
Yes – 2 positions |
Wall Mount |
- (Included) |
Power Adaptor |
KX-A424 or KX-A422 (Optional) |
Audio Features |
Handset, Speaker, Headset Volume |
8 levels (includes echo cancellation and distortion prevention) |
Ringtones |
27 |
Ringer Volume |
8 levels + Off |
Headset Port |
RJ9 jack |
Electronic Hook Switch Control Port |
3.5 mm |
Audio Codec |
G.711a-law / G.711µ-law / G.722 (wideband) / G.729a |
HD Voice |
Yes |
Speaker Phone |
Speaker Phone(Full Duplex / Wideband) |
Keys |
Flexible function keys |
24 (12 keys × 2 pages) |
Software Features |
Phone Book (Local) |
500 |
LDAP Remote Phonebook |
Yes |
XML Remote Phonebook |
Yes |
Call Log Entries |
30 incoming calls + 30 outgoing calls |
Conferencing |
3 parties (within terminal – multi-party dependent on server) |
XML Application |
Yes |
Music on Hold |
Supplied by Host Service (PBX / SIP Server) |
IP Features |
SIP Accounts |
6 |
SIP Compatibility |
RFC 3261 Standard SIP Server, Asterisk, Broadsoft, Panasonic IP PBX |
IP Version |
IPv6 / IPv4 |
DHCP Client |
Yes |
DNS |
Yes |
HTTP |
Yes |
HTTPS |
Yes |
SNTP Client |
Yes |
VLAN (802.1q) |
Yes |
QoS (DiffServ) |
Yes |
Configuration |
Plug & Play Configuration |
Server based configuration, TR-069 |
Manual Configuration |
Internal web Configurator, Local (LCD based) network configuration |
Interface |
Ethernet Ports |
2 |
Ethernet Interface |
10/100/1000 Mbps |
PoE (Power over Ethernet) |
Yes |
Others |
Power Consumption |
PoE
Stand-by: approx. 3.1 W (ECO mode off), approx. 2.9 W (ECO mode on)
Talking: approx. 3.2 W (ECO mode off), approx. 3.0 W (ECO mode on)
Max: 4.2 W
AC Adaptor
Stand-by: approx. 2.8 W (ECO mode off), approx. 2.1 W (ECO mode on)
Talking: approx. 2.9 W (ECO mode off), approx. 2.2 W (ECO mode on)
Max: 4.2 W
|
Operating Environment |
0 °C - 40 °C (32 °F - 104 °F) |
Dimensions
(Width × Depth × Height; excluding the handset, stand attached) |
High position: 252 mm × 179 mm × 188 mm (9.9 in × 7.1 in × 7.4 in)
Low position: 252 mm × 187 mm × 154 mm (9.9 in × 7.4 in × 6.1 in) |
Weight
(with handset,handset cord and stand) |
1,030 g (2.28 lb) |
