Display |
|
LCD Display |
Monochrome Graphical |
|
LCD Size |
132 × 64 pixel 2.3 inch Graphical LCD |
|
LCD Contrast |
6 levels |
|
LCD Backlight |
On/Auto/Off |
|
Install Options |
|
Desk Mount Tilt |
Yes – 2 positions |
|
Wall Mount |
KX-A440 (optional) |
|
Power Adaptor |
KX-A423 (optional) |
|
Audio Features |
|
Handset, Speaker, Headset Volume |
8 levels (includes echo cancellation and distortion prevention) |
|
Ringtones |
27 |
|
Ringer Volume |
8 levels + Off |
|
Headset Port |
RJ9 jack |
|
Electronic Hook Switch Control Port |
- |
|
Audio Codec |
G.711a-law / G.711µ-law / G.722 (wideband) / G.729a |
|
HD Voice |
Yes |
|
Speaker Phone |
Yes |
|
Keys |
|
Programmable Keys |
2 |
|
Software Features |
|
Phone Book (Local) |
500 |
|
LDAP Remote Phonebook |
Yes |
|
XML Remote Phonebook |
Yes |
|
Call Log Entries |
30 incoming calls + 30 outgoing calls |
|
Conferencing |
3 parties (within terminal – multi-party dependent on server) |
|
XML Application |
Yes |
|
Music on Hold |
Supplied by Host Service (PBX / SIP Server) |
|
IP Features |
|
SIP Accounts |
2 |
|
SIP Compatibility |
RFC 3261 Standard SIP Server, Asterisk, Broadsoft, Panasonic IP PBX |
|
IP Version |
IPv6 / IPv4 |
|
DHCP Client |
Yes |
|
DNS |
Yes |
|
HTTP |
Yes |
|
HTTPS |
Yes |
|
SNTP Client |
Yes |
|
VLAN (802.1q) |
Yes |
|
QoS (DiffServ) |
Yes |
|
Configuration |
|
Plug & Play Configuration |
Server based configuration, TR-069 |
|
Manual Configuration |
Internal web Configurator, Local (LCD based) network configuration |
|
Interface |
|
Ethernet Ports |
2 |
|
Ethernet Interface |
10/100 Mbps |
|
PoE (Power over Ethernet) |
Yes |
|
Others |
|
Power Consumption |
PoE
Stand-by: approx. 2.2 W (ECO mode off), 1.9 W (ECO mode on)
Talking: 2.3 W (ECO mode off), 2.0 W (ECO mode on)
Max: 2.8 W
AC Adaptor
Stand-by: 2.0 W (ECO mode off), 1.3 W (ECO mode on)
Talking: 2.1 W (ECO mode off), 1.4 W (ECO mode on)
Max: 2.8 W |
|
Operating Environment |
0 °C - 40 °C (32 °F - 104 °F) |
Dimensions
(Width x Depth x Height; excluding the handset, stand attached) |
High position:
167 mm x 165 mm x 148 mm
Low position:
167 mm x 173 mm x 115 mm |
Weight
(with handset,handset cord and stand) |
691 g
|
